Techon Industrial Solutions Pvt Ltd | Products

Specifications

Size: 3/8" - 4"

Max Capacity: 1.85 - 54 m³/h

Max Pressure: 122 PSI

Max Air Consumption: 0.17 - 8.42 m³/min

Max Air Pressure: 8.4 bar

Max Particle Diameter: 2.5 - 10mm

Corrosive chemicals

Volatile solvents

Viscous, sticky fluids

Shear-sensitive foodstuffs and pharma products

Dirty water and abrasive slurry

Smaller solids

Creams, gels and oils

Handles a wide variety of fluids with high solids content

Self priming

Ability to run dry

Explosion proof

Pumping efficiency remains constant

No mechanical seals, couplings, or motors

Cannot overheat

Low maximum speed

Not very energy efficient

Pulsed flow - requires dampener for reduction

Component	Materials
Pump Casing	Aluminum (AL), Cast Iron (CI), Stainless Steel (SS), Polypropylene (PP), Teflon Lined (PTFE)
Diaphragm	PTFE, Nitrile Butadiene Rubber (NBR), Viton
Ball Valve	Nitrile Butadiene Rubber (NBR), Stainless Steel (SS), PTFE
Valve Seat	Nitrile Butadiene Rubber (NBR), PTFE
